The perfect bike to leave your mark on those long days of training, or to dispute the leadership of the groupBuilding on the technological insights of the Gallium Pro Disc, and now available with a semi-integrated cockpit, the new Gallium CS Disc is the perfect way to make your mark on those long training days. Light, reactive, comfortable, reliable; the ultimate bike. All the engineering knowledge of our World-Tour level Gallium Pro, in a more accessible package.The Gallium CS is the perfect way to make your mark on those long training days, or to challenge for the lead of the group. This is the bike that awaits you for your perfect ride, whether it's a grueling climb, a blistering descent, or a full-on sprint to the cafeteria. Easy to master, intuitive in response and pure riding pleasure, the Gallium CS is equally suited to the touring cyclist and the racer.Ideal for those looking for maximum performance without maximum impact on their wallet - and want to be prepared for that Wednesday night ride that always turns into a KOM quest.basic technologies

• 3D
• Road Race Geometry
• Argon Fit System
• Cyclosportif Layup

Characteristic

• Maximum tire size: 30mm For optimal comfort and compatibility
• Standard Bottom Bracket: BB86
• Box for semi-internal wiring
• Replaceable Derailleur Hanger: A direct mount hanger is supplied
• Built-in carbon chainstay protector against wear from chain movement
• Argon 18 thru-axles : Clean, simple, light and robust

Setting

• Frame: Gallium CS Disc INT (internal cable routing)
• Fork: Gallium CS Disc
• Seatpost: FSA
• Headset: FSA 37 3D w/ TH881-1
• Bottom bracket: SRAM GXP ROAD 86.5
• Front Derailleur: SRAM Rival 22
• Rear derailleur: SRAM Rival 22 WIFLI
• Crankset: SRAM S390 50/34
• Cassette: SRAM PG 1130 11/32
• Chain: KMC X11
• Wheelset: Vision Team TC 30 6-Bolt
• Tires: Vittoria Zaffiro V 700x28c
• Brakes: SRAM Rival
• Discs: SRAM G2 CleanSweep 140mm
• Brake Levers: SRAM Rival 22 Hydro
• Shifters: SRAM Rival 22 Hydro
• Handlebar: FSA Vero Compact
• Stem: FSA Omega Pro OS-167
• Handlebar Tape: Prologo Plaintouch Black
• Seatpost: FSA Gossamer
• Saddle: Quasar S

Geometry:SIZE XXSSeat tube height (cm)42.0Seat tube angle (degrees)75.5Head tube angle (degrees)71.0Top tube length (cm)49.9Chain suspenders length (cm)40.6Wheelbase (cm)96.1BB drop (cm)6.53D Steerer Tube Length (0mm)9.13D Steerer Tube Length (25mm SRS)11.6booth height67.4SIZE XSSeat tube height (cm)45.5Seat tube angle (degrees)74.5Head tube angle (degrees)72.0Top tube length (cm)51.9Chain suspenders length (cm)40.6Wheelbase (cm)96.4BB drop (cm)7.03D Steerer Tube Length (0mm)10.13D Steerer Tube Length (25mm SRS)12.6booth height70.0SIZESSeat tube height (cm)49.3Seat tube angle (degrees)74.0Head tube angle (degrees)72.7Top tube length (cm)53.9Chain suspenders length (cm)40.6Wheelbase (cm)97.2BB drop (cm)7.53D Steerer Tube Length (0mm)12.63D Steerer Tube Length (25mm SRS)15.1booth height73.0

SIZE MSeat tube height (cm)53.0Seat tube angle (degrees)73.5Head tube angle (degrees)72.7Top tube length (cm)55.9Chain suspenders length (cm)41.5Wheelbase (cm)99.7BB drop (cm)7.53D Steerer Tube Length (0mm)14.03D Steerer Tube Length (25mm)16.5booth height76.4SIZE LSeat tube height (cm)56.5Seat tube angle (degrees)73.0Head tube angle (degrees)72.7Top tube length (cm)57.7Chain suspenders length (cm)41.0Wheelbase (cm)100.5BB drop (cm)7.53D Steerer Tube Length (0mm)18.13D Steerer Tube Length (25mm)20.6booth height79.4SIZE XLSeat tube height (cm)59.5Seat tube angle (degrees)72.5Head tube angle (degrees)73.0Top tube length (cm)59.6Chain suspenders length (cm)41.0Wheelbase (cm)101.6BB drop (cm)7.53D Steerer Tube Length (0mm)20.13D Steerer Tube Length (25mm)22.6booth height82.0
